My Nail Gun Doesn't Sink Nails

Hunker may earn compensation through affiliate links in this story.

Things You'll Need

  • Air compressor

  • Air hose

  • Nail gun with nails

  • Nail gun oil

  • Safety goggles


When using an air nailer, wear safety glasses to protect your eyes from flying debris.

A nail gun can make quick work of framing and mounting moldings.
See More Photos

Framing nailers, brad nailers, finish nailers and staplers are all examples of nail guns that operate with a charge of compressed air from an air compressor. Each of these guns has a depth adjustment dial that allows the nail to be driven deeper or less deep, depending on the type of material and the length of nail being driven. The amount of air pressure will affect the depth that the nail reaches. If your nail gun doesn't sink nails, a few adjustments should solve the problem.


Video of the Day

Step 1

Turn on your air compressor and set the pressure gauge to 80 to 90 pounds per square inch (psi).

Step 2

Connect an air hose to the nozzle on the side of the compressor.


Step 3

Insert three drops of nail gun oil into the air connector on the end of the nail gun to lubricate the gun. Place a rack of nails into the nail gun's magazine, then attach the hose to the air connector.

Step 4

Put on safety goggles. Depress the tip of the nailer onto the wood to be nailed, and depress the trigger. If the nail doesn't sink until the head of the nail is flush, turn the rotary knob on the side of the nailer head just above the tip clockwise one full turn, and test the nailer again. Continue rotating the knob and testing until the nailer is sinking nails properly.


Step 5

Increase the air pressure on the air compressor pressure gauge in increments of 5 psi if turning the knob on the nailer doesn't completely sink the nails. The combination of the adjustment on the nailer and additional air pressure will solve the problem.
