How to Change a Thermocouple on a Fireplace

Hunker may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.

The thermocouple on your gas furnace is a heat-sensitive device that transmits a small electrical signal to the gas valve to keep it open when the pilot is on. The thermocouple lasts for 10 years or more, and when it fails, the pilot won't stay lit and the fireplace won't work. Replacing it is a relatively simple job that you can accomplish with a wrench. Before you replace it, though, it's a good idea to test it with a voltmeter to make sure it's actually malfunctioning. If it checks out, the problem with your fireplace could be a blockage in the pilot tube or a faulty gas valve.


Image Credit: tarasov_vl/iStock/GettyImages

What's a Thermocouple?

All gas appliances with standing pilots, such as furnaces and water heaters, have a thermocouple. It's a cylindrical probe about 4 inches long and a quarter to a half inch in diameter that's attached to a 1- to 2-foot length of copper tubing. The probe is positioned next to the pilot opening so that its tip is in the flame when the pilot is on. The other end of the tube connects to the gas valve by a threaded connector.


Video of the Day

The tip of the probe contains a heat-sensitive material that generates a small electric voltage – around 25 millivolts – when it's heated by the pilot flame. The voltage sends a signal to the gas valve to stay open. Without this signal, the valve closes automatically to prevent the release of unburnt gas at the burner. When you light the pilot, you usually have to hold in the gas valve manually for about 10 seconds to give the thermocouple time to heat up. Once it has reached the required temperature, you can release the valve control and the pilot will continue burning.


Test Before You Replace

If you can't get the pilot to stay lit, the chances are good that the thermocouple is faulty, but it's best to check before you replace it. You can perform a simple test with a voltmeter. Set the meter to read millivolts, then hold one probe on the metal copper tube that leads from the gas valve to the pilot orifice and the other probe on the connector that holds the thermocouple tube to the gas valve. Have a helper light the pilot and keep the valve control depressed to heat up the thermocouple probe. About 10 seconds after the pilot starts, you'll get a reading of 25 millivolts if the thermocouple is working. If you get a smaller reading or none at all, the thermocouple needs to be replaced.


Procedure for Replacing a Thermocouple

The only tool you need to replace a thermocouple is a wrench. Turn off the gas supply to the gas valve. Use the wrench to unscrew the connector that holds the thermocouple to the gas valve, then unhook the probe from its clip and pull out the entire thermocouple assembly.


Take the thermocouple to the hardware store to purchase a new one. Many styles are available, so look for one that matches. Once you have the new thermocouple, replace it by snapping the probe back into the clip to hold it at the proper distance from the pilot flame, then screw the other end into the gas valve and tighten it gently with the wrench. Test it by lighting the pilot and making sure the flame stays lit. If you can't get the flame to stay on, try moving the probe slightly closer to the flame until the flame does stay lit.
