How to Install a Peephole in a Metal Door

Hunker may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.
Image Credit: George Mdivanian / EyeEm/EyeEm/GettyImages

Peepholes, also called door viewers, allow the occupants of a home to see who is outside before opening the door. These devices provide a safe method of seeing through the door, yet are small enough that they do not pose a threat to the door's integrity or security features. If your existing door does not have a peephole, you can install one very easily on your own. These units are available in many different styles and colors to complement your door as well as your existing hardware.


Things You'll Need

How to Install a Peephole in a Metal Door

Step 1: Measure the Door's Thickness

Measure the thickness of your door, using a tape measure. Most commercial doors are 1 3/4 inches thick, while most residential doors are 1 3/8 inches thick. It is critical that you choose a peephole that is the right length to fit your door. An incorrectly sized unit may not be functional and will definitely detract from the door's aesthetic appeal.


Video of the Day

Step 2: Buy a Peephole to Fit

Choose a peephole of stainless steel or brass to avoid rust and corrosion on exterior doors. Other metals will rust over time and may even stain the surrounding door surface.

Step 3: Determine a Location

Decide where you will place the peephole on the door. The unit should be installed so that every member of the family can see through it. Shorter family members or children should be able to use the peephole without a step stool. Taller members may have to bend down for access. Once you've chosen a mounting height, measure the width of the door to determine the midpoint, and mark the location for the peephole with a pencil.


Step 4: Drill the Hole

Drill a hole for the viewer that is the same diameter as the unit itself. For peepholes that are not the same diameter across their entire length, follow the installation instructions to determine how large to drill the hole. You'll need a bimetal hole saw for this job. A bimetal hole saw is used just like a wood hole saw but is designed for cutting holes in metal. Look for a unit with an attached arbor, or pilot bit, in the center. This pilot bit makes it easier to make smooth, easy cuts with your hole saw.



Always wear safety glasses to protect your eyes when drilling metal.

Step 5: File the Hole's Edges

File away any rough edges from around the hole using a round metal file. This will create a smooth surface for installing your peephole.

Step 6: Install the Peephole

Insert the lens portion of the peephole through the front of the door. Add the scope portion by inserting it through the interior side of the door. Twist the two pieces together until they are tightly fastened.


Step 7: Calk the Peephole (As Needed)

Caulk around the peephole to seal gaps or air spaces as needed. Depending on the size of the hole relative to the peephole, you may not need to add caulk. Caulk can also be helpful if you have an odd-sized peephole and can't find a bit or hole saw of exactly the right diameter.


Look for specialty peepholes if you have special security or visual concerns. Some larger or higher-quality units provide a very clear view of the exterior and may expose a larger area. For those with poor vision, magnified viewers may make it easier to see the exterior.
