ADA Requirements for a Pedestal Sink

Hunker may earn compensation through affiliate links in this story.
ADA pedestal sinks should provide sufficient clearance for wheelchairs and concealed drain parts.
Image Credit: franticstudio/iStock/GettyImages

Unlike a vanity sink with a cabinet, pedestal sinks allow handicapped people in wheelchairs to access a sink to perform basic hygiene activities, such as hand washing and tooth brushing. As the name suggests, the sink is mounted on a pedestal base, allowing access under the sink and on both sides of the pedestal. The American with Disabilities Act sets guidelines for all bathroom fixtures, from ADA bathtub requirements to ADA pedestal sink requirements, for those items to be called handicapped accessible.

ADA Compliant Pedestal Sink Height

The ability to access a sink is of utmost importance for an ADA compliant pedestal sink. The slim pedestal base makes it easier for people in wheelchairs to get close to the bowl, but the height of the bowl is important. It needs to leave enough clearance for the wheelchair without being too high so the person can still reach it.

The bowl of the pedestal sink should be at least 27 inches from the ground level and not more than 34 inches high, according to the ADA requirements. This ensures that handicapable persons can reach the water and sink bowl and that there is enough clearance for their knees under the bowl. The pedestal should be set back against the wall or be thin enough so it fits between the wheels and the person's legs. The sink must be at least 6 1/2 inches deep.

Operable Sink Parts

Operable parts in an ADA bathroom sink with legs or a pedestal sink refer to the specific parts a person must use to activate the water. This includes the spout from which the water flows and the diverters that initiate the hot and cold water flow. The pedestal sink should not be so deep that the operable parts cannot be reached by the average user in a wheelchair.

They should be easy to operate with one hand. No tight grasping or twisting of the wrist should be required to turn on the water in an ADA pedestal sink. The guidelines state the force required to turn on the water should be no more than 5 lbs. The types of operable parts may be lever-operated, two-handled turn-style, push-type or motion activated.

Read more: How to Measure a Bathroom Sink

Exposed Plumbing Parts

The valves and P-trap drain assembly are exposed under many pedestal style sinks. ADA pedestal sinks require these parts to be concealed within the pedestal to prevent people from hurting themselves by bumping into the parts. Pedestal sinks are specifically designed so the pedestal base fits over the drain assembly to conceal it and prevent harm. If for any reason these parts cannot fit inside the pedestal base, they should be covered with a plumbing pipe cover to ensure safe use of the sink.

Read more: What Is the Height of a Handicap Toilet?

Required Wheelchair Clearance

To be wheelchair accessible, a sink should be installed to provide enough clearance on all sides for a wheelchair to easily navigate around. The area around the sink should be unobstructed, with at least 4 feet in front of the sink so a wheelchair can approach the sink and turn around when finished.

If a sink is being installed beside another fixture, plumbing code requires that there be at least 36 inches of clearance from the closest edge of the fixture to the center of the ADA compliant pedestal sink. If the sink is installed next to a wall, the clearance from the wall to the center of the sink should also be 36 inches.
