How to Adjust a Kohler Shower Temperature Regulator

Kohler shower temperature regulators feature a built-in adjustable stop that helps prevent scalds. The stop is set at a safe temperature, and physically prevents the shower handle from being turned beyond that setting. The accuracy of the setting depends on a constant hot-water temperature from the water heater. If the water heater is replaced, or the thermostat on the water heater is adjusted, it will be necessary to adjust the Kohler shower temperature regulator.

...
You can adjust a Kohler shower temperature regulator in just a few minutes.

Preparation

Step 1

Remove the retaining screw from the shower handle using either a Phillips screwdriver or Allen wrench. Pull the handle off and set it aside.

Step 2

Take off all adapters, inserts and sleeves between the handle and the faceplate, noting the order in which they are removed.

Step 3

Remove the screws holding the faceplate to the regulator. Remove the faceplate and set it aside.

Minor Adjustment

Step 1

Rotate the valve stem and collar clockwise to start the flow of hot water.

Step 2

Turn the set-screw on the temperature regulator collar counterclockwise to increase the maximum water temperature or clockwise to decrease the maximum water temperature.

Step 3

Turn the set-screw until the desired temperature is reached. Rotate the valve stem and collar counterclockwise to shut off the water.

Step 4

Install the faceplate and screws. Install the adapters, inserts and sleeves in the proper order. Install the handle and retaining screw.

Major Adjustment

Step 1

Remove the O-ring from the valve stem, followed by the collar.

Step 2

Turn the valve stem clockwise until the desired maximum temperature is reached.

Step 3

Slide the collar onto the valve stem with the set-screw seated against the tab on the regulator housing. Slide the O-ring onto the valve stem until it is seated against the collar.

Step 4

Turn the valve stem counterclockwise to turn off the water.

Step 5

Install the faceplate and screws. Install the adapters, inserts and sleeves in the proper order. Install the handle and retaining screw.
