How to Troubleshoot Scag Mowers

Hunker may earn compensation through affiliate links in this story.
Your Scag mower is effective on large lawns.
See More Photos

Scag mowers are commercial lawn mowers that can provide professional lawn maintenance. The mower may fail to crank and ignite for a number of common reasons, ranging from an old spark plug to an air gap problem between the flywheel and magnetic coil in the engine assembly. You can troubleshoot and fix your Scag mower even if you have no previous experience with repairing lawn equipment. No special tools or items are required.

Advertisement

Step 1

Check the fuel level of the Scag mower if it refuses to start, and ensure that there is gas in the tank.

Video of the Day

Step 2

Open the Scag mower's engine cover if the engine will crank but will not start. Consider replacing your spark plug, which may be worn due to age. Disconnect the plug wire from the spark plug and reconnect the plug wire to the new spark plug you have obtained.

Advertisement

Step 3

Attempt to ignite the Scag mower's engine now that the spark plug has been replaced.

Step 4

Open the mower's engine cover again if the engine still won't ignite. Check the air gap. This is the gap created between the magnetic coil and the flywheel. You may find the magnetic coil by following the spark plug's wire to the rear of the Scag mower's engine assembly. The flywheel sits just behind the coil. Measure the air gap's width to ensure it falls between 0.010 and 0.015 of an inch. A good benchmark for this width is comparing it to the thickness of a business card.

Advertisement

Advertisement

Step 5

Loosen the magnetic coil within the Scag mower's engine assembly by using a wrench if the air gap is outside of the required specification. Apply pressure to the coil to adjust the gap as necessary.

Advertisement

Advertisement
