How to Remove Desk Drawer Locks

Kenneth Crawford

Desk drawers use a cam lock much like file cabinets. The key cylinder turns a metal tab that releases the drawer from the drawer cavity. If you misplace a key or just want to change locks, you will need to remove the existing desk drawer lock.

The method you use to remove a desk drawer lock depends on how the manufacturer has secured the lock to the drawer. Some manufacturers simply screw the lock on, while others use a clip to secure the lock.

Tip

If the drawer is locked and you do not have a key, drill through the cylinder where you would normally insert the key and turn the cylinder with a flat-head screwdriver to unlock the drawer.

  1. Open the desk drawer and examine the back of the lock where it fits against the back of the drawer front. Some locks secure with two screws at each side.

  2. Insert the key into the lock cylinder and turn the key counterclockwise to move the lock tab from over the left or right retaining screw. If you do not have the key, turn the tab using a pair of vise grips.

  3. Remove the screws with a Phillips-head screwdriver. Pull the back of the lock away from the cylinder and pull the lock cylinder out of the drawer.

  4. Look for the C-clip securing the lock to the drawer if there are no screws. Pry the C-clip off with a flat-head screwdriver. Pull the lock bolt tab off the rear of the lock and pull the cylinder out of the drawer.

The Drip Cap

  • Desk drawers use a cam lock much like file cabinets.
  • Remove the screws with a Phillips-head screwdriver.
  • Pull the lock bolt tab off the rear of the lock and pull the cylinder out of the drawer.
